The manual for the Epilog M2 40 Laser cutter. Please note that you may not use the laser cutter without first taking the introduction course.
Laser Cutter Documentation
IDM-8342 Multi-Meter
The manual for the Multi meters can be downloaded here:Multi-Meter:
In the event that the multi-meter is giving strange readings, or will not enter the desired mode, a good place to start is with a factory re-set:
Lab Equipment
This page contains links to documentation and tutorials for the equipment permanantly located in Manufakturet. Please note: INTRODUCTION COURSES ARE MANDATORY for some of these facilities.
Keysight 1000x Oscilloscope
A basic tutorial in PDF format, somewhat more advanced than the video introduction on the tutorials page, and the user manual.
My measurements are ten times too high???
If this happens there are two possibilities:
- Your oscilloscope probe has a little switch on it, which is set to 10 x. In this case, change the setting on the probe.
- The probe setting on the channel you are reading on is set to 10:1. In this case, select the channel, then choose 'probe', and adjust the gain ration to 1:1.
Power Supply RPE-2323
